YUEJIN compressed garbage truck
Products detail
| YUEJIN compressed garbage truck | ||
| Model | NJ5080ZYS5 | |
| Cab |
Type | Single cabin |
| Tilted | S | |
| No. of Seats | 3 | |
| Dimension |
Overall Dimension(mm) | 6481*2200*2550 |
| Wheelbase(mm) | 3308 | |
| Min. Ground Clearance(mm) | 180 | |
| Weight |
Kerb Weight(kg) | 5690 |
| Payload(kg) | 2390 | |
| G.V.W.(kg) | 8275 | |
| Power |
Engine Brand | SHANGCHAI |
| Engine Model | SC28R125Q5A | |
| Engine Type | common rail SCR | |
| Emission Standard | CHINA 5 | |
| Displacement (cc) | 2776 | |
| Engine Power(Kw/rpm) | 92/3000 | |
| Engine Torque（N.m/rpm） | 340/1800~2200 | |
| Gearbox Model | WLY6TS40 | |
| Gearbox Ratio | I:5.32,II:2.91,III:1.82,IV:1.33，V:1，VI:0.77 | |
| Gearbox Torque（N.m） | 400 | |
| Rear Axle Ratio | 4.916 | |
| Max. Speed(km/Hr) | 100 | |
| Max. Climb Ability | 30% | |
| Loading |
Chassis Frame Section Dimension （mm） | 180*70*4 |
| Suspension | FR & RR Leaf Spring, 8/10+6 ,8/10+6 | |
| FR&RR Axle Payload | 2.3T/4.2T | |
| Tire Size | 7.50R16LT 14PR | |
| Brake |
Serving Brake Type | Hydraulic |
| Parking Brake Type | central drum | |
| ABS | S | |
| Comfort |
A/C | S |
| Power Steering | S | |
| Power Window | S | |
| air spoiler | o | |
| Front Parabolic Spring | N/A | |
| Others |
Voltage | 24V |
| Fuel Tank Volume | 85L | |
Main specification of garbage compactor |
control type | automotive |
| effective volume of dustbin （m3) | 6.2 | |
| effective volume of precompressor hopper（m3) | 0.8 | |
| drain tank volume（m3) | 0.34 | |
| single filling and compressor cycle time（S) | ≤17 | |
| discharging working time（S) | ≤45 | |
| loading working time (overturning barrel) （S） | ≤9 | |
| *Note:"S" indicates "Standard" "O" indicates "Optional"， "N/A" indicates "Not Available" | ||
